Massey Ferguson 5130

Massey Ferguson 5130

The Massey Ferguson 5130 Heavy-Duty Wheel Rake provides the strength and features that commercial operations demand, like in-cab control, a heavy-duty frame and rake beams, and rake wheels with rubber-mounted teeth and solid wheel panels that can handle heavy or damp crops. Walking beam rear axles and tandem wheels provide more stability over rough ground and limited oscillation. The large 60-inch (1,524 mm) diameter rake wheels are each equipped with 36 rubber-mounted rake teeth for a cleaner job of raking. Wheel hubs are cast iron, for longer life than steel plate with anti-wrap guard. Each rake wheel has its own torsional dampening spring, so it floats independently. Plus, the amount of ground pressure on the rake wheels is adjustable.

Quick Specs

  • Wheels: 17
  • Working Width: Up to 72'
  • Transport Width: 12.3'
  • Weight: 5800 LBS
